Feature

1. Pure sine wave output.off grid power inverter dc 12v ac 220v 1000w 3000w 5000w 6000w 10000w
2. Intelligent LCD integration display.
3. Low frequency toroidal transformer lower loss.
4. AC charge current 0~30A adjustable, three working modes selectable.
5. Peak power more than 3 times, full-automatic and perfect protection function.
6. Added fault code query function, easy to monitor the operation in real time.
7. Supports diesel or gasoline generator, adapt any tough electricity situation.
8. Combine industrial and home usage, wall-mounted design, convenient installation.

Product Details

Wiring Diagram

1. Battery number and capacity should be configured according to the rated voltage of the solar power system or invertor;

2. We offer 3 optional working modes (transfer time≤4ms):

01 Grid priority mode: When the grid and battery are connected to the invertor, grid will supply power to the loads directly after voltage being stabilized and charge batteries via invertor. When the grid is cut off, the battery will automatically continue to supply power via invertor.
02 Energy saving mode: If the power of the connected AC loads is lower than 5% of the invertor’s rated power, there will be no output from the invertor. Only the chip of invertor is working. The power consumption of the invertor is only 1~6W. The LCD shows the output voltage 0. If the power of the connected loads is over 5%, within 5S the invertor will automatically convert DC to AC to supply power for the loads . The LCD shows the output voltage.
03 Battery priority mode: When the grid and battery are connected to the invertor, battery will supply power to the loads first. When battery capacity is not enough, the grid will continue to supply power automatically.
